i36 BE5010 Dual-Band WiFi7 Ceiling Access Point

i36 is a dual-band Wi-Fi7 Ceiling Access Point that can work in both 2.4 GHz and 5 GHz bands, with a wireless access rate of up to 5010Mbps. Through Wi-Fi7's unique MLO and 2.5G network port, the wired transmission rate is greatly improved to meet the needs of multi-device interconnection. Through Tenda CloudFi, remote management of devices can be achieved.

Explore

Documents

Tenda AP Installation Guide(multi-language)

i36 Datasheet

Symbols on Products and Materials

Datasheet

You can click here to export the current parameters (.docx)
Model	i36
Category	Ceiling
Dimension	Φ250.6*55 mm
Interface	1100/1000/2500Mbps Ethernet Port (PoE) 110/100/1000Mbps Ethernet Port
Button	1*Reset
LED Indicator	1*SYS
Maximum Power Consumption	17.4W
Power Supply	PoE 802.3at
Max. Number of Clients	256
Recommended Clients	100
Antenna	24dBi + 34dBi
2.4GHz maximum power	• CE: <20 dBm (2.4 GHz, EIRP) • FCC: <25 dBm (2.4 GHz)
5GHz maximum power	• CE: <23 dBm(5 GHz, EIRP) • FCC: <25 dBm(5 GHz)
Reception Sensitivity	2.4GHz 802.11b -98dBm 2.4GHz 802.11n (MCS7) -77dBm 5GHz 802.11a -95dBm 5GHz 802.11n (40M-MCS7) -76dBm 5GHz 802.11ax (80M-MCS11) -64dBm
Frequency Range	2.4GHz&5GHz
Standard&Protocol	IEEE 802.11b/g/n/ac/ax/be
Maximum wireless speed	2.4GHz: 688Mbps 5GHz: 4323Mbps
Bandwidth	20MHz/40MHz/80MHz/160MHz
Operating Mode	AP/Client+AP
Max. No. of SSID	2.4GHz: 8 5GHz: 4
Hide SSID	Supported
OFDMA	Supported
Beamforming	Supported
Fast roaming（802.11k/v/r）	Supported
WEP	Supported
WPA-PSK	Supported
WPA2-PSK	Supported
WPA	Supported
WPA2	Supported
WPA3-ASE	Supported
Access control	Supported
Adjustable power transmit	Supported
Automatic channel	Supported
AP isolation	Supported
Guest network	Supported
Connected clients control	Supported
RSSI Threshold	Supported
Weak signal terminal elimination	Supported
Prioritize 5 GHz	Supported
VLAN tagging for SSID	Supported
LED control	Supported
MU-MIMO	Supported
Diagnostics tool	Supported
Reboot at specified interval	Supported
Schedule Reboot	Supported
Device management	Web, Router, CloudFi APP, AP Controller
System Logs	Supported
Firmware upgrade	Supported
Reboot	Supported
Reset	Supported
Backup configuration	Supported
Restore configuration	Supported
Default login IP	10.16.16.169 192.168.0.254
Default Login Username	-10℃ ~ 40℃
Operation Temperature	-10℃ ~ 40℃
Operating humidity	10%~90% non-condensing
Storage temperature	-30℃ ~ 70℃
Storage humidity	5%~90% non-condensing
